U8Ⅱ-X UAV Integrated Propulsion System | Motor, ESC, Propeller
$400.00
Description
Detail Information
- Fast and convenient
- Free of complicated mounting process
- Turn-key system, perfect compatibility, superb cost performance
- Modularized propulsion system
Specifications
| Product Model | Exposed wire length | Arm size | Boom weight (incl. wire) | Configu ration | Shaft Diameter | Idle Current（24V） | Rated Voltage(Lipo) | Internal Resistance | IP | Peak Current(180s) | ESC | Max Power (180S) | Propeller Recommendation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| U8II-XKV85 | 630mm | 132.9*87.1*57.2mm | 460g | 36N42P | IN:15mm | 0.6A | 12S | 225mΩ | / | 19.1A | ALPHA 60A 12S V1.2 | 1000W | MF2815 |
| U8II-XKV100 | 630mm | 132.9*87.1*57.2mm | 450g | 36N42P | IN:15mm | 0.8A | 12S | 170mΩ | / | 29.3A | ALPHA 60A 12S V1.2 | 1500W | MF2815 |
| U8II-XKV150 | 630mm | 132.9*87.1*57.2mm | 450g | 36N42P | IN:15mm | 1.3A | 6S | 85mΩ | / | 29.7A | ALPHA 60A 6S | 580W | MF2815 |
| U8II-XKV190 | 630mm | 132.9*87.1*57.2mm | 450g | 36N42P | IN:15mm | 1.7A | 6S | 48mΩ | / | 43.7A | ALPHA 60A 6S V | 940W | MF2815 |
