X-705 Combo Pack Coaxial Type (Integrated Propulsion System ) UAV Motor Alpha 80A 125/260KV
$760.00
T-MOTOR X-705 Standard Integrated Propulsion delivers efficient thrust and reliable power for UAVs, ideal for aerial missions needing stability and performance.
Description
Detail Information
- Polymer propellers are not recommended for coaxial setups
- Free of complicated mounting process
- Turn-key system, perfect compatibility, superb cost performance
- Fast and convenient
Specifications
| Model | X-705KV125 | Lead Cable Length | 580mm |
| Dimension | 126.5*81.5*136.1mm | Arm Set Weight(Incl. Cable) | 1395g |
| Configuration | 24N28P | Shaft Diameter | IN:8mm OUT:8mm |
| Idle Current (24V) | 1.5A | Rated Voltage (Lipo) | 12S |
| Internal Resistance | 63mΩ | ESCRecommendation | ALPHA 80A 12S |
| Max. Power (180s) | 576W | PropellerRecommendation | G26*8.5 |
Technical Drawing
