AX Series Brushless Motor

SKU: TM-AX335-B Category: AX Series Fixed-Wing Motors Brand: T-MOTOR

Description
Reviews (0)

Description

Detail Information

AX Series Brushless Motor

A Propulsion System Designed For Fixed-Wing Cruising Aircraft

There are two interfaces based on internal and external designs: one built-in rear shaft design, the other one external propeller adapter design with excellent impact resistance and overload resistance. To provide stable and efficient power support for different types of fixed-wing cruising aircrafts.

SPECIFICATIONS Recommendations

Model： AX335-B KV： KV425 Motor Weight（Incl. Cable）： 260g

Model：

AX335-B

KV：

KV425

Motor Weight（Incl. Cable）：

260g

Rated Voltage (Lipo)： 6-8S Propeller Recommendation： 12-13〃 Rated power： 700W

Rated Voltage (Lipo)：

6-8S

Propeller Recommendation：

12-13〃

Rated power：

700W

Take off weight： 2-3kg Max. Power： 1500W Max. Thrust： 1.6kg

Take off weight：

2-3kg

Max. Power：

1500W

Max. Thrust：

1.6kg

GOOD HEAT DISSIPATION

Stable operation of equipment. The hollowed and tilted design in front cover increases the speed of air entering to optimize heat dissipation performance and get cooling better.

Impact resistance and overload resistance

High-quality military wire and large-size bearings ensure the working of the motor under high overload conditions.

Specifications

Weight (Incl. Cable)	260g	Motor Dimensions	Φ39*76.5mm
Internal Resistance	50mΩ	Lead	Enameled Wire*120mm
Configuration	12N14P	Shaft Diameter	IN:5 OUT:5
Recomended battery/voltage	6S-8S	Idle Current(10V)	1.7A
Peak Current(180s)	60A	Max Power (180S)	1500W(8S)
Recomended ESC/Propeller	60A(6S)/60A(8S)/12*20

Test Data

Type	Propeller	Throttle	Voltage (V)	Current (A)	Power (W)	RPM	Torque (N*m)	Thrust (g)	Efficiency (g/W)	Operating Temperature (℃)
AX335-B KV425	12*20	40%	22.17	3.24	71.82	3131	0.161	202	2.82	96
		45%	22.15	4.40	97.52	3505	0.200	255	2.62
		50%	22.13	5.97	132.15	3902	0.252	308	2.33
		55%	22.10	7.74	171.13	4272	0.300	380	2.22
		60%	22.08	9.44	208.47	4599	0.345	432	2.07
		65%	22.04	11.45	252.33	4896	0.393	493	1.95
		70%	22.01	13.53	297.78	5198	0.438	551	1.85
		75%	21.97	16.48	362.03	5566	0.502	629	1.74
		80%	21.92	19.42	425.56	5880	0.559	702	1.65
		90%	21.81	26.41	575.93	6509	0.679	856	1.49
		100%	21.66	35.69	773.13	7163	0.825	1045	1.35
	12*20	40%	29.56	5.25	155.13	4123	0.288	341	2.20	197
		45%	29.52	7.08	208.89	4562	0.346	419	2.01
		50%	29.49	9.18	270.67	4979	0.413	507	1.87
		55%	29.46	11.36	334.51	5375	0.475	591	1.77
		60%	29.42	13.93	409.67	5752	0.544	672	1.64
		65%	29.35	17.90	525.41	6260	0.642	795	1.51
		70%	29.29	22.13	648.09	6703	0.740	921	1.42
		75%	29.22	26.73	781.07	7131	0.833	1040	1.33
		80%	29.15	31.00	903.78	7503	0.919	1154	1.28
		90%	28.98	41.87	1213.35	8242	1.108	1389	1.14
		100%	28.76	55.45	1594.84	8985	1.311	1647	1.03
Note: Motor temperature is motor surface temperature at 100% throttle running 1mins. (Date above based on benchtest are for reference only, comparion with that of other motor types is not recommended.)

Technical Drawing

Packing List

Before using this product, please check if all the items listed above are included in the packaging. If there are any missing items, please contact our online customer service or leave message to “[email protected]” in time.
